• Model NO.：acrylic panel
• Decorations & Ornaments Type：House
• Feature：Eco-Friendly
• Condition：New
• Customized：Customized
• Acrylic Panel Impact Strength：≥13.3j,M
• Acrylic Panel Refractive Index：1.49+0.01
• Acrylic Panel Tensile Modulus：≥2760MPa
• Acrylic Panel Compressive Yield Strength：≥103MPa
• Acrylic Panel Compressive Modulus Elasti：≥2760MPa
• Acrylic Panel Shear Ultimate Strength：≥55MPa
• Acrylic Panel Rockwell Hardness：≥mscale 90
• Acrylic Panel Specific Gravity：1.19+0.01
• Acrylic Panel Flexural Ultimate Strength：≥97MPa
• Acrylic Panel Transparency：≥92%
• Transport Package：Carton Case, Outside with Iron Frame
• Specification：any sizes
• Trademark：xc-acrylic
• Origin：China
• HS Code：39205100
• Production Capacity：150000kg,Month

PROPERTIESVALUEMethod
ASTMVALUEMethod
DINDensity (specific weight)1,19 g/cm3D 7921,19 g/cm353479Modulus of elasticity32.000 Kg./cm2D 7903200 N/mm253457Tensile Strenght740 kg/cm2D 63874 kg/cm253455Flexural Strenght1200 kg/cm2D 790120 kg/cm253452Elongation at break3,0 %D 6383,0 %53455Impact Strenght (Izod)2,0 kg/cmD 2562,0 kg/m253453Impact Strenght (Charpy)25 kg/cmD 25627 kg/m253453Rockwell HardnessM 100D 785//Ball Drop H98/30//200 N/mm253453

            THERMAL PROPERTIES

PROPERTIESVALUEMethod
ASTMVALUEMethod
DINCoefficient of thermal conductivity5,0 10-4 cal/cm s° CC 1770,19 W/m°C52612Deflection temperat.- 1,8 N/mm2105 °CD 648105 °C53461Softenig Point (Vicat)> 115 °CD 1525> 115 °C53460Coef. Linear Thermal Expantion7,5 10-5 1/°CD 69675 10-4 1/°CVDE0304/1Specific Heat0,35 cal/g°C///

     ELECTRIC PROPERTIES

PROPERTIESVALUEMethod
ASTMVALUEMethod
DINDielectric Strength20 kV/mmD 14920 kV/mm53461Volume Resistivity1 1015 Ohm/cmD 257//Surface Resistivity1 1014 OhmD 2571 1014 Ohm53482Transversal Resistivity> 1015 Ohm/cmD 257Dielectric Constant (50 Hz)3,5D 1503,553483Power Factor (50 Hz)0,05D 1500,0653483








            OPTICAL PROPERTIES

PROPERTIESVALUEMethod
ASTMVALUEMethod
DINRefractive Index n20 D1,49D 5421,4953491Light Transmittance92%D 1003/A92 %5036Turbidity (Haze)0,5%D 1003/A//

            CHEMICAL PROPERTIES

PROPERTIESVALUEMETHODMedium molecular weight800 - 1000 103 umaviscousResistance to acidsgood/Resistance to basesgood/Resistance to chlorous solvents ( methylene chloride, chloroform, trichloroethylene etc.)low/Resistance to non chlorous solvents (acetone,alcohol, petrol, etc.)medium/

            REACTION TO FIRE

PROPERTIESVALUEMETHODFlame propagation22 - 28 mm/min.ASTM D635/63Igniting T.280 - 300 °CASTM D 93Autoigniting T.425 °CDIN 51794Calorific power6600 kcal/kg/Oxygen index18ASTM D28/63Flammabilityclass B2DIN 4102Smoke density (Flamming)Dm 50NBS

            WATER AND GAS ABSORPTION

PROPERTIESVALUEMETHODWater absorption rate30 mgISO 62, m.lMax % increase of weight after water immersion2,1%ISO 62, m.lCoef.of steam permeability2,3 10-10 g/cmPa/Coef.of N2 permeability4,5 10-15 g/cmPa/Coef.of O2 permeability2,0 10-14 g/cmPa/Coef.of CO2 permeability1,1 10-13 g/cmPa/Coef. of air permeability8,3 10-15 g/cmPa/
